Features
Uses colour alerts to notify you of the radio mode, potential emergencies and specific events.
RADIO PROFILES
Configure radios to adjust audio level, lighting and tones through user-selected or automated options. Whether on surveillance or working in bright sunlight, you can customize settings as needed.
TEXT MESSAGING
Offers a free form or canned messaging solution so you can efficiently and discreetly send and receive messages to and from subscribers or dispatch operators.
UNIFIED CALL LIST
Consolidates all call lists to make all information about a particular contact easily accessible.
VOICE ANNOUNCEMENT
Navigate through channels/talkgroups and zones while an audible, pre-recorded voice file provides a description of the selected channel or zone.
P25 PHASE 2 CAPABLE
Provides twice the voice capacity so you can add more users to your system without adding frequencies or infrastructure.
GPS LOCATION
With its integrated GPS receiver, the outdoor location of a vehicle can be transmitted to map-based location software.
MULTIBAND OPERATION
Multiple frequency bands supported with best-in-class transceiver specifications and performance.
SEAMLESS SCAN
Scan multiple protocols, including FDMA and TDMA systems and multiple RF bands.
ENCRYPTION
Equipped with FIPS certified encryption hardware for secure communications.
EXPANSION SLOT
Add option cards and data applications to upgrade to the latest functionality.
MEMORY
Expandable memory slot lets you store future data applications. Increased memory is available as your technology needs grow.
Specification Sheet
APX 7500 consolette specifications
Racing to an emergency or repairing a power outage, every moment matters. The right control station can make all the difference in making sure communications are clear, continuous and coordinated – across multiple users, agencies and miles. The APX™ 7500 Consolette is the ideal complement to your dispatch console. It’s the low-cost, mid-power RF control station for the ASTRO® 25 system when you want a wireless dispatch solution. Plus, you can use it as an emergency backup station when infrastructure is off-line or for wireless access to different system types for increased interoperability between agencies.
APX™ 7500 Project 25 Multi-Band Mobile Radio
APX 7500 Spec Sheet
Performance Characteristics
-
Frequency band
VHF, UHF, 700 MHz, 800 MHz
-
Frequency range
700/800 (764-870 MHz), VHF (136-174 MHz), UHF R1 (380-470 MHz)
UHF R2 (450 – 520MHz)
-
Power levels
10-35 watts/700/800 MHz, 25-110 watts/VHF, 25-110 watts/UHF R1
10-45 watts/UHF R2
-
Encryption
Yes
-
Encryption type Algorithms
AES, DES, DES-XL, DES-OFB, Advanced Digital Privacy (ADP)
-
Channel spacing
6.25, 12.5, 25
Physical Characteristics
-
Configurations
Dash Mount, Remote Mount, Motorcycle, Multi-Control Head, Consolette
-
Dimensions H x W x D
2.0" x 7.0" x 9.6"
-
Weight
3kg
-
Display
Alphanumeric
-
Keypad
Yes
Radio Features
-
Channels
1250
-
Integrated voice and data
Yes
-
Text messaging capable
Yes
-
Advanced software features
Over the Air Programming (OTAP), Over the Air Rekeying (OTAR)
Technology
-
Digital technology
Yes
-
System type
Conventional, SmartZone trunking, SMARTNET trunking
