Features
• Ease-of-operation in the most demanding situations – unsurpassed audio quality, intuitive keypad and high-definition, colour display combined with a sleek yet durable design
• Dust and water resistant to IP 54. Rain, salt, fog, and dust protection tested to MIL 810 C/D/E/F for the standard control head
• Motorcycle control head rated IP67 for dust and water resistance
• Comprehensive model options available – for use in the office, in a vehicle - car, boat, motorcycle
• User training and familiarisation easier by design. Features the same cellular-style menu, icons and colour display that have established Motorola's MTH800 handheld and MTP850 portable
• Multiple language capability – support for European, Arabic and Cyrillic characters (plus many others)
• Access and query information on the move – integrated WAP* browser and Multi Slot Packet Data provide unique, high-bandwidth connectivity for real-time access to mobile office applications and user databases
• Tailor to specific requirements. Faster programming and connectivity via USB, ETSI compatible Peripheral interface (PEI) and programmable I/O ports* ensures tighter integration with third-party applications
• Full suite of TETRA security functions – air interface, SIM card* and end-to-end encryption
• Receive assistance when and where it is needed – hitting the emergency button not only alerts colleagues to critical situations but sends and updates dispatch on the user’s location
• Switch to covert mode at the press of a button
• Integrated GPS receiver delivers locationbased services. Knowing where your resources are enables you to allocate tasks based on up to date information
• Transform workflows and improve performance with the highest levels of network security, resilience and value available. Motorola’s TETRA solutions leverage more than 75 years of excellence in the most critical and demanding
environments.
• Stay at the forefront of TETRA development with a future-proof platform that meets the promise of the broadband world tomorrow.
• Build on the widest portfolio base in the industry. Motorola’s in-house technologies, solutions and best-in-class business relationships deliver the complete TETRA solution.
• Compatibility and interoperability assured. As an early pioneer of TETRA, Motorola has been a driving force in standards’ developments and product innovation.
Specification Sheet
TETRA Ear Microphone Spec Sheet
Motorola Ear Microphone System: Compact, Durable Accessory that Meets Demanding Mission Critical Needs
TETRA iTM Spec sheet
TETRA Integrated Terminal Management Specification Sheet
Physical Characteristics
-
Dimensions H x W x D (dash and desk)
60 x 185 x 175 mm
-
Display
Alphanumeric
-
Keypad
Yes
-
Dimensions H x W x D
49 x 170 x 155 mm (radio only), 72 x 185 x 53 mm (standard control head), 58 x 185 x 58 mm (Motorcycle control head)
-
Weight
1370 (radio only), 1670 (radio with control head), 448 (Motorcycle control head only)
-
Configurations
Motorcycle
-
Emergency button
Yes
Performance Characteristics
-
Encryption
Yes
Radio Features
-
Scan
Priority, Talk group
-
Emergency signalling
Yes
-
Call tones
True
-
Programmable buttons
Yes
-
Text messaging capable
Yes
-
GPS capable
Yes
-
Caller ID
Yes
-
Selective radio inhibit
Yes
-
Status calls
Yes
User Environment
-
Operating temperature
-30 to +60 (°C)
-
Storage temperature
-40 to +85 (°C)
-
Humidity
ETS 300 019-1-5 Class 5.1 and 5.2; EIA / TIA 603 (95%)
-
Dust and water
Dash / Desk / Remote IP54 (Cat 2); Motorcycle Control Head IP67 (Cat 2)
Voice Services
-
Talkgroups
2048 (TMO) & 1024 (DMO)
-
Phone book
1000 persons. Up to 6 number per entry – max 2000 entries
-
Scan lists
40 lists, 20 talkgroups / list
-
Ambience listening
Yes
-
Transmit inhibit
Yes
TMO Services
-
Private call
Half / Full Duplex (TMO)
-
Telephony
Full Duplex (TMO)
-
DGNA
up to 2047 groups (TMO)
DMO Services
-
Group call
Late entry
-
Compatibility
Gateway & Repeater (DMO)
Emergency Voice Services
-
Smart emergency
DMO / TMO / DMO to TMO
-
Hot mic
Configurable timers
-
Location
Send on emergency
-
Emergency target address
Individual or Group
-
Alarm
Emergency Status
Data Services
-
Status messaging
100 Alias messages
-
Packet data (PD)
7.2kbps - 28.8 kbps gross; Single or Multi Slot
-
PEI
AT Commands; TNP1; enables simultaneous SDS & PD
-
Short data service (SDS)
20 messages inbox; Individual or group target address; Send/receive during calls
Security Features
-
Air interface encryption algorithms
TEA2, TEA3, TEA1
-
Air interface encryption security classes
Class1 (clear), Class2 SCK), Class3 (DCK, CCK & GCK)
-
Key provisioning
Secure provisioning tool (key variable loader KVL)
-
Network access
Temporary enable disable (Stun), Permanent enable disable (Kill)
-
Authentication
Infrastructure initiated and made mutual by terminal
GPS Specifications
-
Simultaneous satellites
12
-
Mode of operation
Autonomous or assisted (A-GPS)
-
GPS antenna
Integrated in TETRA antenna
-
GPS sensitivity
-152 dBm / -182 dBw
-
GPS accuracy
5 meter (50% probable)
-
Location protocols
ETSI LIP, Motorola LRRP
